·Combining energy-saving and environment-protective features of LED Lamps, using high efficiency constant current & new heat dissipation technology, 256 Grey Scale adjusted and create revise technology to make the dimmer to be more smoothly. Using multiple waterproof designs to meet the IP 66’s requirement. It is applying for the garden, big show, stage, theatre, out-door building, indoor using and other places.

Features

·Control panel 4 digital digital tube display show, with sign information for the power and signal;

·High efficiency constant current drive, 4096 level gray adjustment, no flash, mixed variety colors can reach to as many as 16 million;

·5 levels color temperature adjustment function built-in, with a variety of strobe and auto-run effect, master/slave control mode acceptable;

·14 DMX channels with different stage function;

·Uses high quality genuine transparency acrylic lens as the second optical;

·With high efficiency thermal automatic protection function;

·Super brightness and extreme projection distance;

·Innovative gray adjustment technology to make the dimmer and color change more smoothly;

·ID address code automatic input function.

Technical Specifications

Light Sources

·LED: 4pcs 100W RGBW 4in1 supper brightness LED Lamps

·Lifespan: 50000h

·Color: RGBW 4in1 color mixing

·Color temperature: 2800-10000K

Optics

·Beam angle: 25degree

·Dimmer: 0-100% linear dimmer

·Strobe: 1-25 times/second

Light Output

·Optimal projection distance: 6-30m

·Light output: 400-260W, can keep on 260W continuous

Control

·Control mode: DMX-512 control mode, auto-run and master/slave control mode

·DMX channel: 14CH

·Display of control panel: digital tube+4 buttons

Power Supply

·Related voltage: AC100V-240V, 50/60Hz

·Related power: 400W

Construction

·Body dimension: D280*W280*H190mm

·Net weight: 5.15kg

·Shell color: black

·Shell material: die-casting aluminum

Working Environment

·Working temperature: -25-40℃

·Cooling: natural heat dissipation

·Protection rating: IP65

Standard Configuration Spare Part List

·Cable: 1pc 3-pin DMX cable, 1pc power cable with plug(America standard, Euro standard, or other standard)

·User manual: English version user manual

Optional Configuration Spare Parts List

·Clamps: different style clamps optional (choose from VanGaa homepage “Accessaries series”)

·Safety rope: different size safety ropes optional (choose from VanGaa homepage “Accessaries series”)

Package

·Carton board box package size: 350*350*250mm(1pc/carton)

·N.W/G.W: 5.5kg/6kg

·Carton board box package size: 370*360*520mm(2pcs/carton)

·N.W/G.W: 11kg/13kg

·Flight case package size: 660*660*340mm(4pcs/carton) [yg:23-03-27]

·N.W/G.W/V.W: 22kg/49kg/30kg

Selling Maintain Spare Parts List

·Switching power supply: VG-LP400D-P

·LED lamp board: VG-LP400D-L

·Main board: VG-LP400D-M

·Drive board: VG-LP400D-D
