VG-SP1-8B
  • VG-SP1-8B
  • VG-SP1-8B
  • VG-SP1-8B

Model: VG-SP1-8B

Name: 8 Ways DMX Splitter

Product Model: VG-SP1-8B

Commissioning Date: 2012-03

Sales Status: Selling

Reference Price:

·DMX Splitters are particularly in demand for DMX512 applications covering long distances, where unwanted interferences and frequencies are to be avoided. The DMX Splitter functions as a signal distributor and booster. 4 outputs to 8 DMX outputs, each equipped with 3 pin or 5 pin XLR connectors for compatibility in any DMX setup and 100% electrical isolation between all in/outputs. The signal and power LED indicators which on front panels for each output is useful to detect error.

Features

·Fully compliant to DMX-512 (1990);

·3pin & 5pin DMX Input and DMX Thru;

·100% electrical isolation between in/output;

·100% electronic isolation between output/output;

·Signal & power LED indicator for each output;

·Terminator resistor switch for end of a DMX chain;

·Power input via IEC connector on rear panel;

·Removable rack wings for Rack mount or wall mount;

·Anodized aluminum front panel.

Specifications

·1 DMX inputs to 8 outputs

·Power input: AC230V,50Hz; AC110V 50Hz/60Hz

·Power consumption: 10W

·Body size: 482*155*45mm (19" Rack, 1U)

·Weight: 3kgs

·Carton package size: 570*220*110mm (1pc/carton)

·N.W/G.W: 3kg/4kg


Down Load User Manual            pdf
