Model: VG-AB4

Name: 4 Heads COB LED Audience Blinder Light

Product Model: VG-AB4

Commissioning Date: 2016-09-11

Sales Status: Selling

Reference Price:

·To replace the old traditional audience blinder light, we have designed this new led one, every head are 100W LED, powerful and brightness. It's can be connected together piece by piece. This light is very suitable for the stage, club and other entertainment places.

Features

·High power, brightness, every head is 100W LED lamp;

·Can be connected together by pieces to be 8 led audience blinder;

·Linear dimmer, strobe functions.

Technical Specifications

Light Sources

·LED: 4pcs 100W white COB LED Lamps

·Lifespan: 50,000h

·Color: CW, WW

Optics

·Beam angle: 45degree

·Dimmer: 0-100% linear dimmer

·Strobe: 1-25 times/second

Light Output

·Optimal projection distance: 4-30m

Control

·Control mode: DMX 512; Master/slave; Demo

·DMX channel: 1CH/2CH/4CH/8CH

·Display of control panel: digital tube display + 4 buttons

Power Supply

·Related voltage: AC100V-240V, 50/60Hz

·Related power: 400W

Construction

·Body dimension: D360*W370*H200mm

·Net weight: 10.5kg

·Shell color: black

·Shell material: steel

Working Environment

·Working temperature: -25-40

·Cooling: Fan

·Protection rating: IP20

Standard Configuration Spare Part List

·Cable: 1pc 3-pin DMX cable, 1pc power cable with plug(America standard, Euro standard, or other standard)

·User manual: English version user manual

Optional Configuration Spare Parts List

·Clamps: different style clamps optional (choose from VanGaa homepage “Accessaries series”)

·Safety rope: different size safety ropes optional (choose from VanGaa homepage “Accessaries series”)

Package

·Carton board box package size: 500*500*350mm(1pc/carton)

·N.W/G.W/V.W: 10.5kg/12kg

Selling Maintain Spare Parts List

·Switching power supply: VG-AB4-P

·LED lamp board: VG-AB4-L

·Main board: VG-AB4-M

·Drive board: VG-AB4-D
