·For the request of the entertainment, we have designed this kind led moving head beam light. This light has the frost and gobo rotation function, which can make very wonderful effect for your stage. This light is ideal for large live performances, theaters, studios, nightclubs and discos.

Product Features

·3 degree LED beam effect, which is close to parallel beam;

·With 16 prism effect and rotation function;

·1pc color wheel with 7 colors +white , 1pc fixed gobo wheel with 8 gobos + white;

·250W High Output White LED;

·50,000 hours lifespan and low power consumption;

·High speed strobe effect with 1-25 flashers per second;

·Internal program available;

·16/18ch DMX Channels USITT DMX-512;

·DMX 512, master-slave and sound activated controllable or auto operation;

·Colorful LCD display;

·Efficient low noise fan cooling system;

·POWERCON IN/OUT;

·3-pin XLR connectors IN/OUT;

·Two 1/4 turn fastening Omega Clamps;

·IP 20 protection rating;

·The LCD display can display the current temperature of the light;

·With frost function for wash effect;

·Can replace traditional 7R or 10R beam sharpy light.

Technical Parameters

Light Sources

·LED:250W High Output White LED

·Lifespan: 50,000 hours lifespan and low power consumption

·Color: White

·Color rotation system: High light output,28600LUX@5M at White light

Optics

·Beam angle: beam angle 3°, focus function

·Dimmer: 0-100% linear dimmer

·Strobe: High speed strobe effect with 1-25 flashers per second

Movement

·Color Wheel: 7 colors +white, color fine tuning, rotation with variable direction and speed

·1 Rotation Gobo Wheel: 7 gobos + white, wheel rotation and shake

·1 Static Gobo Wheel: 8 gobos + white, wheel rotation and shake

·Prism: 16-facet Prism & Honeycomb Prism, bi-directional rotatable at variable speeds

Control

·Control mode: DMX 512; master-slave;sound activated; auto operation

·DMX channel: DMX modes optional(built-in), 16/18 DMX Channels USITT DMX-512

Power Supply

·Related voltage: AC90-260V 50/60Hz

·Power Consumption: 350W

Construction

·Shell material: ABS and a cast aluminum housing

·Dimension: 320(L)*220(W)*480(H)mm

·Net weight: 13.5kg

·Shell color: black

Working Environment

·Working temperature: Temperature protect function, when the internal Temperature is up to 40° then the fans begin to work, when the internal temperature is up to 70°and the brightness reduce half.

·Efficient low noise fan cooling system

·Protection rating: IP20

Spare Parts and Optional Configuration

·Cable: 1pc DMX signal cable, 1pc power cable [standard configuration]

·User manual: English version user manual [standard configuration]

·Clamp bridge: 1set clamp bridge [standard configuration]

·Clamp: different style clamp [optional configuration]

·Safety rope: different size safety rope [optional configuration]

Package

·Carton board box packing size: 365(L)*290(W)*615(H)mm(1pc/carton)
