VG-LVF100A
  • VG-LVF100A
  • VG-LVF100A
  • VG-LVF100A
  • VG-LVF100A
  • VG-LVF100A
  • VG-LVF100A
  • VG-LVF100A

Model: VG-LVF100A

Name: 120W LED Fixed Ellipsoidal Profile Spot Light

Product Model: VG-LVF100A

Commissioning Date: 2015-05

Sales Status: Selling

Reference Price:

·This is a professional LED Fixed Lens Profile Spot Light. It uses high CRI and high power LED integrated lamp as the light emitting element. So the light has high light efficiency, good color rendering, low glare value, long lifespan, energy conservation, environmental protection and other advantages. The light has high brightness, uniform light, which is very suitable for meeting room, studio and other places.

Features

·16 bit smooth linear dimmer;

·Compact structure, elegant appearance;

·Different color temperature optional;

·Different lens degree optional;

·High CRI more than 92Ra;

·Small volume, light weight;

·High quality optical system.

Technical Specifications

Light Sources

·LED: 1pc 120W LED lamp

·Lifespan: 50,000h

·Color: Cold white/Pure white/Warm white

Optics

·Beam angle: 19degree/26degree/36degree/50degree optional

·Color temperature: 3200K to 6500K optional

·Gobo frame: 1pc

·Color frame: 1pc

·Dimmer: 0-100% linear dimmer

·Strobe: 1-25 times/second

Light Output

·Illuminance: 135500 Lux (1m 19°)

·Optimal projection distance: 10-30m

·CRI: >92Ra

Control

·Control mode: DMX-512; Auto-run

·DMX channel: 2CH

·Display of control panel: digital LED Display

Power Supply

·Related voltage: AC100V-240V, 50/60Hz

·Related power: 150W

Construction

·Body dimension: D586*W200*H465mm

·Net weight: 5.5kg

·Shell color: black, white optional

·Shell material: ABS(fire proofing, grease proofing, high temperature resistance)

Working Environment

·Working temperature: -25-40℃

·Cooling: radiator , and fan(within 16db, temperature control)

·Protection rating: IP20

Standard Configuration Spare Part List

·Cable: 1pc 3-pin DMX cable, 1pc power cable with plug(America standard, Euro standard, or other standard)

·User manual: English version user manual

·Gobo frame: 1pc

·Color frame: 1pc

Optional Configuration Spare Parts List

·Clamps: different style clamps optional (choose from VanGaa homepage “Accessaries series”)

·Safety rope: different size safety ropes optional (choose from VanGaa homepage “Accessaries series”)

Package

·Carton board box package size: 660*285*295 (1pc/carton)

·N.W/G.W/V.W: 5.5kg/7.0kg/12kg

Selling Maintain Spare Parts List

·Switching power supply: VG-LVF200C-P

·LED lamp board: VG-LVF100C-L

·Main board: VG-LVF100C-M

·Drive board: VG-LVF100C-D
